A 3 axles lowboy semi trailer is a semi-trailer with a low height from the ground. It is capable of transporting various construction machinery and mining machinery. Due to its low platform, it can transport some ultra-high and long large goods. In addition, it can also transport construction machinery such as excavators and bulldozers.
The main structure of a low-bed semi-trailer includes suspension system, axle, frame, hydraulic ladder, tires, traction device and braking system, etc. Compared with flatbed semi-trailers, low-bed semitrailers are also equipped with a gooseneck device.
#image_376381167 {
width: 100%;
}
#image_649941619 {
width: 100%;
}
3 Axles Lowboy Semi Trailer Specifications
| Brand: | FUDENG |
| Dimension: | 13000*3000*1750mm (Customized) |
| Load Capacity: | 50-80Ton |
| Rear Ramps: | Spring Mechanial or Hydraulicy Cyliner |
| Main Beam: | Q345B High tension carbon steel |
| Axle: | 3 Axles, FUWA/BPW/Chinese Brand |
| Suspension: | Mechanial Suspension or Air Suspension |
| King Pin: | 2.00inch or 3.5inch |
| Leaf Spring: | 90mm(W)*16mm(T)*10 Layer |
| Landing Gear: | 28T lifting capacity with two speed |
| Tire: | 12R22.5, 315/80R22.5, 10R22.5, 13R22.5 tires |
| Brake System: | WABCO, ABS Optional |
| Electrial System: | 24V; 7 ways receptacle; LED lamps |
| Accessories: | One tool box, one spare tire carrier |
| Color: | Optional |
#image_1717969826 {
width: 100%;
}
In addition to three-axle low-bed semi-trailers, we also have other semi-trailers with different configurations. As a direct manufacturer of semi-trailers, we are also able to provide you with specially configured semi-trailers. If you have any needs, you can contact us and we will reply to you as quickly as possible.
